Flexo Printing sleeves and bridges
Tech Sleeves® is a sister company of AV Flexologic and a global manufacturer of customized flexo printing sleeves and bridges. With 5 decades of experience and innovation, AV Flexologic and Tech Sleeves® have developed a new build-up formula that offers up to 40% lighter sleeves with increased durability and toughness.
- UV-cured Vinyl Ester resin outer layer
- Lightweight technology
- Very durable and longlasting
- Rubber sealed edges to prevent damage
- Metal reinforced slot
Trusted by
Unique Printing Sleeve Options
2
Rubber sealed edges
Decreases wear and tear of the sleeve. The edges are shock absorbent, therefore sleeve damage is prevented.
3
Full inner metal ring
The most strong and durable slot solution. It increases the lifetime of the sleeve.
4
Smart Sleeve
Sleeve with a RFID chip and magnet that store identification numbers, repeat sizes and quality reports from the TIR
5
Hard sealed edges
Protects the core from damage by ink and solvents. Ensures the longevity of the sleeve.
6
Metal cutting line
The metal cutting line has an optimum width of 6mm and helps the operator to apply tape without cutting the sleeve
7
Conductive
For anti-static applications that require conductivity from the outer layer to the base mandrel.
1
Rubber sealed edges
Decreases wear and tear of the sleeve. The edges are shock absorbent, therefore sleeve damage is prevented.
2
Full inner metal ring
The most strong and durable slot solution. It increases the lifetime of the sleeve.
3
Smart Sleeve
Sleeve with a RFID chip and magnet that store identification numbers, repeat sizes and quality reports from the TIR
4
Hard sealed edges
Protects the core from damage by ink and solvents. Ensures the longevity of the sleeve.
5
Metal cutting line
The metal cutting line has an optimum width of 6mm and helps the operator to apply tape without cutting the sleeve
6
Conductive
For anti-static applications that require conductivity from the outer layer to the base mandrel.
Tech Sleeves® Superior Quality Adapters
Standard flexo bridges
All Tech Sleeves adapters have full Outer metal ring including registration pin and full Inner metal ring including registration slot. Double sealed edges are also included and the bridges are available in Separate Air or Air-through version. There are different additional options for the standard adapters such as: Lead edge full metal ring, Miller (ball) valves, Soft-coated bridge.
Lead edge full metal ring
Protects the front edge of the bridge from damage by repeated handling of sleeves. Increases durability and lifetime.
Separate air bridge
Bridges of which the air is fed by a separate air connection from the press (or the mounting machine) from the drive side.
Miller (ball) valves
Spring-assisted ball valves close off the airflow when the position is not covered by a sleeve. Improves airflow and mountability.
Air-through bridge
Bridges of which the air is fed by air holes in the mandrel.
Soft coated bridge
Soft Coated Tech Bridges are used to carry flexible, thin sleeves (seamless sleeves) that are available in densities of 40, 50 and 60 ShA. They can be Separate air connection or air-through
1
Standard flexo bridges
2
Lead edge full metal ring
3
Separate air bridge
4
Miller (ball) valves
5
Air-through bridge
6
Soft coated bridge
Business case
The lightweight sleeves are available in two versions. The Tech Light version is the standard sleeve with a milled slot, while the Tech Pro Light has rubber-sealed edges for maximum protection and longevity.
Advantages of Tech Sleeve Light
Lightweight technology
The new technology reduces the weight of sleeves without compromising their performance.
Very durable
Increased durability thanks to the UV-cured Vinyl Ester resin outer layer.
Dimensional stability
One of the stiffest sleeve in the flexo market with an 82 ShD outer layer.
