Introduction: Why Mounting Still Matters in the Flexo Workflow

Despite advances in press technology, inks, and substrates, plate mounting remains a foundational step in flexographic printing. It influences everything downstream - print quality, press uptime, waste levels, and repeatability.

Historically treated as a manual skill passed from operator to operator, mounting has undergone a transformation, driven by automation, precision engineering, and lean manufacturing demands. This article explores the journey from manual to automated plate mounting, the real operational impact, and why it’s a critical investment for any flexo converter.

The Limitations of Manual Mounting: Hidden Costs and Daily Headaches

Manual mounting has been the industry standard for decades, but it presents persistent challenges:

• Operator variability leads to inconsistent mounting and print results
• Human errors such as skewing, air bubbles, or tape misplacement are common
• Long mounting times (up to 10 min/sleeve) slow down changeovers
• High rework and waste from misaligned plates or pressure issues
• Safety concerns from repetitive handling and awkward postures

In high-mix, short-run environments, these inefficiencies become costly bottlenecks.

Automation 101: What a Modern Mounting System Really Offers

An automated plate mounter is more than just a faster way to mount. Modern systems like AV Flexologic’s SAMM 3.0 provide:

• Vision-based alignment systems with micron precision
• Motorized plate application to ensure consistent pressure
• Automatic tape application and cutting (optional add-ons)
• Repeatable workflows regardless of operator experience
• Intelligent controls with digital job storage and barcode scanning

These features create a standardized, traceable process that fits perfectly into lean operations.

ROI: How Automation Pays Off - Fast

The return on investment (ROI) from automated mounting systems is clear and quantifiable:

• Press uptime increases by reducing mounting errors and remounting
• Make-ready times drop significantly (e.g., from 10 min/sleeve to under 2 min)
• Waste is cut due to precise plate alignment and fewer registration issues
• Training time shortens, reducing onboarding costs for new operators
• Labor efficiency improves, freeing skilled operators for more value-added tasks

Typical ROI periods range from 6 to 18 months depending on production volume.

Reducing Operator Dependency and Training Pressure

In today’s flexo landscape, skilled mounting operators are harder to find and retain. Automation reduces this dependency by:

• Making precision repeatable across shifts, plants, and countries
• Allowing faster onboarding of new operators
• Minimizing reliance on tribal knowledge or individual skill

This is especially useful for global converters standardizing operations across facilities.

The Evolution of Automated Mounting at AV Flexologic

AV Flexologic introduced the first automated plate mounting system over 20 years ago. Since then, the technology has matured significantly:

• Early systems relied on static cameras and manual rotation
• Today’s automatic flexo plate mounting machines such as the SAMM 3.0 offers robotic movement, dynamic calibration, and intuitive HMIs
• Integrations now include automated taping, sleeve inspection, and data reporting
• Flexibility to handle diverse sleeve types and plate sizes

This innovation trajectory reflects AV’s ongoing commitment to precision, speed, and standardization.

Enhancing Quality Assurance with Traceability and Digital Reporting

Modern mounting systems do more than mount—they generate data. With traceability features:

• Operators can scan jobs to load stored parameters automatically
• Each mount is logged with date, time, and operator ID
• Images or measurement logs can be stored for QA documentation
• Error reporting and alerts help catch deviations early

This builds confidence with both internal QA teams and external brand clients.

A Leaner Pressroom: Integration and Workflow Synergies

Automated mounting supports lean principles and continuous improvement:

• Integrates seamlessly with sleeve inspection systems (like AV’s SQIS)
• Helps standardize mounting protocols across shifts
• Reduces WIP (work in progress) through faster plate prep
• Minimizes variation that leads to troubleshooting or rework

Combined with digital job queues and ERP connectivity, it creates a more agile, data-driven workflow.

Is It Time to Automate? A Checklist for Converters

You should consider automating plate mounting if:

• You run 6+ jobs per day per press
• You’ve seen print defects due to mounting inconsistency
• You face labor shortages or high operator turnover
• You’re pushing for shorter lead times or faster changeovers
• You want to increase press uptime without expanding headcount

Mounting may seem like a small step—but its impact on productivity and quality is massive.

Conclusion: Standardizing Excellence Through Automation

Manual plate mounting served the industry well—but it cannot meet the demands of modern flexo printing. Automation brings speed, consistency, safety, and transparency to a process that has remained manual for too long.

With SAMM 3.0 and other innovations, AV Flexologic is helping converters transform mounting from a variable into a strength—unlocking higher print quality, faster changeovers, and a leaner production environment.
